PreSonus Studio 1810c

Specifications

General

• Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz

• Converter Resolution: 24-bit

• Converter Dynamic Range: 14 dB

• Converter Dynamic Range: 114 dB

Microphone Inputs

• Maximum Level: +16 dBu, min gain

• Gain Range: 80 dB

• Frequency Response: 20 Hz - 20 kHz (unity gain)

• Dynamic Range: 110 dB (A-wtd, min gain)

• THD + N: 0.005% (1 kHz, 0dBu, unity gain)

• EIN: -128 dBu (A-wtd, 20 kHz BW, Rs=150Ω, max gain)

• Input Impedance: 1400Ω

• Phantom Power: 48V (>10 mA per channel)

Line Inputs

• Maximum Level: +21 dBu (balanced, min gain)

• Gain Range: 40 dB

• Frequency Response: 20 Hz-20 kHz (unity gain)

• Dynamic Range: 112 dB (A-wtd, min gain)

• THD + N: 0.005% (1 kHz, +18 dBu, min gain)

• Input Impedance: 10 kΩ

Instrument Inputs

• Maximum Level: +15 dBu (unbalanced, min gain)

• Gain Range: 80 dB

• Frequency Response: 20 Hz - 20 kHz (min gain)

• Dynamic Range: 112 dB (A-wtd, min gain)

• THD + N: 0.020% (1 kHz, +10 dBu, min gain)

• Input Impedance: 1M Ω

Main Outputs

• Type: ¼" TRS female, DC Coupled

• Maximum Level: +18 dBu, balanced

• Frequency Response: 20Hz - 20kHz (unity gain)

• Dynamic Range: 108 dB (A-wtd, unity gain)

• THD + N: 0.004% (1 kHz, -1 dBFS, unity gain)

Line Outputs

• Type: ¼" TRS female, DC coupled

• Maximum Level: +18 dBu, balanced

• Frequency Response: 20 Hz - 20 kHz

• Dynamic Range: 108 dB (A-wtd, -60 dBFS)

• THD + N: 0.004% (1 kHz, -1 dBFS, unity gain)

Headphone Outputs

• Maximum Power: 150 mW/channel (60Ω load)

• Frequency Response: 20 Hz - 20 kHz (unity gain)

• Dynamic Range: 103 dB (A-weighted, 1 kHz, unity gain)

• THD + N: 0.250% (1 kHz, 150 mW, unity gain)

• Impedance Working Range: 32Ω to 600Ω

Physical

• Height: 1.75" (44 mm)

• Width: 12.5" (317 mm)

• Depth: 5.5" (140 mm)

• Weight 3.2 lbs (1.45 kg)
