ADJ Dotz Par RGBL

$399.98

Drawing on the popularity of Chip On Board (C.O.B.) LED from the Dotz Par fixture, the ADJ Lighting Dotz Par RGBL uses the latest advancements in lighting technology with a RGBL (red, green, blue, lime) C.O.B. LED for a smooth, even field, high CRI output, advanced color mixing and tunable white color temperature control from 2700K to 6500K.

Drawing on the popularity of Chip On Board (C.O.B.) LED from the Dotz Par fixture, the ADJ Lighting Dotz Par RGBL uses the latest advancements in lighting technology with a RGBL (red, green, blue, lime) C.O.B. LED for a smooth, even field, high CRI output, advanced color mixing and tunable white color temperature control from 2700K to 6500K.

SOURCE:

• Light Source: 16x 3.5-Watt RGBL C.O.B. LED (4x Red, 4x Green, 4x Blue 4x Lime)

• 20,000 Hours Rated Life

PHOTOMETRIC DATA:

• 18° Beam Angle (With Included Lens)

• 29.7° Field Angle (With Included Lens)

• CRI: 85.3

• CRI R9: 79.1

• Lux: 957 (@ 3m, Full On)

• Footcandles: 89 (@ 3m, Full On)

• Lumens: 1102

EFFECTS:

• Linear Color Temperature Control (2700K to 6500K)

• Preset Color Temperatures

• 16-Bit Fine Color Control (Red, Green, Blue Lime)

• 64 built-in Color Macros

CONTROL:

• 4-button, DMX digital display on rear panel

• 6 Operational modes: Static Color Mode, RGBL Dimmer Mode, Program Mode, Sound Active Mode, Wireless RF and DMX Controlled

• Supports RDM (Remote Device Management)

• With Wired Digital Communication Network

• 6 selectable Dimming Modes (Standard, Stage, TV, Architectural, Theatre Stage 2)

• 4 selectable Dim Curves (Linear, Square Inv. Squa, S-Curve)

• 1200Hz LED Refresh Rate

• LED pulse and strobe effect

• Electronic Dimming: 0 - 100%

CONSTRUCTION  / CONNECTIONS:

• Plastic construction

• IEC Locking, In/Out Power connectors

• Indoor 5-pin, XLR DMX, In/Out sockets

• Scissor Yoke

ELECTRICAL / THERMAL:

• Multi-voltage operation: AC 100-240V, 50/60Hz

• Max Power LInk: 30 @120V., 57 @230V.

• Max power consumption: 36W

• Fuse protected: T1A/250V (5*20mm)


DIMENSIONS / WEIGHT:

• Length: 5.19" (131.8mm)

• Width: 8.23" (209mm)

• Height: 8.72" (221.44mm)

• Weight: 4.41lbs. / 2kg.

APPROVALS / RATINGS:

• CE

• cETLus (4010765)

• FCC

• IP20

INCLUDED ACCESSORIES:

(1) Power Cord

(1) Lens Kit

Specifications subject to change without notice.

UPC: 810087372835
